Name: 100kg Load Cell MT1260 with 2m Cable – Industrial Grade Weighing Sensor
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Célula de carga MT1260-100kg 2m
Availability: InStock

Casa Produtos

100kg Load Cell MT1260 with 2m Cable – Industrial Grade Weighing Sensor

Detalhes do produto:

Lugar de origem:	China
Marca:	Mettler Toledo
Número do modelo:	Célula de carga MT1260-100kg 2m

Condições de Pagamento e Envio:

Quantidade de ordem mínima:	1 conjunto
Preço:	Negociável
Detalhes da embalagem:	Caixa de carrinho
Tempo de entrega:	10-30 dias
Habilidade da fonte:	2000 conjuntos por mês

Contato

Descrição de produto detalhada

Produto:	Mettler Toledo Load Cell	Capacidade Máxima:	220 lb (100 kg)
Materiais:	Alumínio, passivado	Metrologia:	NTEP III 5.000d OIML C3
Precisão:	Padrão	Classificação de protecção:	IP67
Tamanho da plataforma (LxW):	400 mm x 400 mm	Conectividade:	Análogo
Cabos:	PVC
Destacar:	100kg load cell with 2m cable , industrial grade weighing sensor , Mettler Toledo load cell with warranty

100kg Load Cell MT1260 with 2m Cable – Industrial Grade Weighing Sensor

Key Features

High-performance single point load cell with off-center compensation
Industrial-grade aluminum construction with passivated finish
IP67 protection rating for durable operation in harsh environments
Includes ATEX Zone 1/21/2/22 approvals for hazardous area usage
Metrology approvals: NTEP III 5,000d and OIML C3

Product Description

The MT1260 compression weigh module is designed for industrial weighing applications where its top plate and base plate are compressed when weight is applied. This robust load cell can be directly attached to the ground, piers, or structural beams, making it ideal for large platform scales including truck and railroad track scales, as well as tank, hopper, and silo weighing systems.

Technical Specifications

Attribute	Value
Product	Mettler Toledo Load Cell
Maximum Capacity	220 lb (100 kg)
Material	Aluminum, passivated
Metrology	NTEP III 5,000d OIML C3
Accuracy	Standard
Protection Rating	IP67
Platform Size (LxW)	400 mm x 400 mm
Connectivity	Analog
Cable	PVC

Reliable Performance

This load cell utilizes advanced strain gauge technology and premium aluminum materials to ensure long-term durability and consistent performance. The off-center compensation design effectively handles platform moments, while the standardized metrology approvals guarantee measurement accuracy.
