Name: MT1041 20kg Load Cell – Durable Weighing Sensor with 6 Meter Wire
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Célula de Carga MT1041-20kg 6m
Availability: InStock

Casa Produtos

MT1041 20kg Load Cell – Durable Weighing Sensor with 6 Meter Wire

Detalhes do produto:

Lugar de origem:	China
Marca:	Mettler Toledo
Número do modelo:	Célula de Carga MT1041-20kg 6m

Condições de Pagamento e Envio:

Quantidade de ordem mínima:	1 conjunto
Preço:	Negociável
Detalhes da embalagem:	Caixa de carrinho
Tempo de entrega:	10-30 dias
Habilidade da fonte:	2000 conjuntos por mês

Contato

Descrição de produto detalhada

Produto:	Mettler Toledo Load Cell	Capacidade Máxima:	20 kg (44 lb)
Materiais:	Alumínio, passivado	Metrologia:	NTEP III 5.000d OIML C3
Precisão:	padrão	Classificação de protecção:	IP67
Dimensões da Plataforma (CxL):	400 mm x 400 mm	Conectividade:	Análogo
Cabos:	20 pés (6 m)
Destacar:	MT1041 20kg load cell , Durable weighing sensor , Load cell with 6 meter wire

MT1041 20kg Load Cell – Durable Weighing Sensor with 6 Meter Wire

Attribute	Value
Product	Mettler Toledo Load Cell
Maximum Capacity	44 lb (20 kg)
Material	Aluminum, passivated
Metrology	NTEP III 5,000d OIML C3
Accuracy	Standard
Protection Rating	IP67
Platform Size (LxW)	400 mm x 400 mm
Connectivity	Analog
Cable	20 ft (6 m)

Product Description

A compression weigh module is designed so that its top plate and base plate will be squeezed toward each other when weight is applied to it, and it can be attached directly to the ground, piers or structural beams. Compression weigh modules are typically used in multiples under large platform scales such as truck and railroad track scales and in tank, hopper and silo weighing. Capacities for compression load cells, which are within compression weigh modules, range from 3 kg to 300 tons.

For Mid Size Platforms - Load Cell MT1041

Accuracy

A high performance single point load cell. Load cell is off-center compensated thus copes with platform moments. Metrology approvals include OIML as standard.

Reliable Strain Gage Technology

Usage of best aluminum materials & SG technology guarantee long term durability.

Hazardous Area Usage

ATEX Zone 1/21/2/22 approvals as standard. No need to ask for options, no need to stock variations - one fits all.

Specifications

Material	Aluminum, passivated
Material No	72208501
Maximum Capacity	44 lb (20 kg)
Protection Rating	IP67
Connectivity	Analog
Cable	PVC
Platform Size (LxW)	400 mm x 400 mm
Accuracy	Standard
Metrology	NTEP III 5,000d OIML C3
